Caterpillar Ground engaging tool (G.E.T) K series bucket tooth system Caterpillar new bucket system K80 K90 K100 drive through K110 K130 K150 K170 hammerless

Short Description:

Caterpillar K series are more and more used on new machineries including excavators and wheel loaders.

All items as below.

If you have requirements, please contact us sales. We are always at your service.


Product Detail

Product Tags

K series / Bucket tooth K80 K90 K100 K110 K130 K150 K170
Wide/Flare bucket tooth 222-1080 222-1090 223-8100 223-8110286-2111 223-8130 195-5151 223-8170
Extra Duty bucket tooth 220-9081 220-9091 220-9101 286-2112232-2111 264-2131 264-2151 264-2171
Penetration bucket tooth 220-9082 220-9092 220-9102 220-9112286-2113 220-9132 229-7152 232-0172
Penetration Plus bucket tooth 220-9083 220-9093 220-9103 220-9113286-2114 220-9133 229-7153 232-0173
Spike / Sharp / tiger bucket tooth 220-9087 220-9097 220-9107 220-9117286-2115 220-9137 229-7157 232-0177
Double Spike / Twin tiger bucket tooth 220-9088 309-1098 220-9108 220-9118286-2116 220-9138 229-7158 232-0178
General purpose bucket tooth 220-9089 220-9099 220-9109 286-2117220-9119 220-9139 229-7159 232-0179
Heavy Penetration bucket tooth 222-1081 222-1091 223-8101 232-2112286-2118 264-2132 264-2152 264-2172
Heavy Abrasion bucket tooth 222-1082 222-1092 223-8102 223-8112286-2119 223-8132 229-7156 232-2178
Caterpillar K series / excavator bucket adapter K80 K90 K100 K110 K130 K150 K170
two-strap Center adapter 220-9084 220-9094 220-9104 469-4311 469-4311
2-strap LH corner adapter 220-9086 220-9096 220-9106 469-4313 469-4313
2-strap RH corner adapter 220-9085 220-9095 220-9105 469-4312 469-4312
two strap center adapter 232-0114(60mm) 232-0130(70mm) 195-9154(80mm) 232-2170(90mm)
two strap corner adapter RH 232-0115(60mm) 232-0131(70mm) 195-9155(80mm) 232-2171(90mm)
two strap corner adapter LH 232-0116(60mm) 232-0132(70mm) 195-9156(80mm) 232-2172(90mm)
two-strap corner adapter RH (increase toe angle) 232-2085 232-2096 232-2105 264-2115(60mm) 264-2135(70mm) 264-2155(80mm) 264-2175(90mm)
two-strap corner adapter LH (increase toe angle) 232-2086 232-2095 232-2106 264-2116(60mm) 264-2136(70mm) 264-2156(80mm) 264-2176(90mm)
Straght corner RH (zero toe angle) 229-7085 223-8095 232-0105
Straight corner LH (zero toe angle) 229-7086 223-8096 232-0106
Caterpillar K series / loader bucket adapter K80 K90 K100 K110 K130 K150 K170
two-strap center adapter 222-1094 (40mm) 223-8104(45mm) 232-2114(51mm) 223-8134(63.5mm) 195-7154(70mm) 232-2174(76mm)
two-strap RH adapter 222-1095 (40mm) 223-8105(45mm) 232-2115(51mm) 223-8135(63.5mm) 195-7155(70mm) 232-2175(76mm)
two-strap LH adapter 222-1096 (40mm) 223-8106(45mm) 232-2116(51mm) 223-8136(63.5mm) 195-7156(70mm) 232-2176(76mm)
two-strap center adapter 232-0134(51mm) 232-0154(63.5mm) 232-0174(70mm)
two-strap RH adapter 232-0135(51mm) 232-0155(63.5mm) 232-0175(70mm)
two-strap LH adapter 232-0136(51mm) 232-0156(63.5mm) 232-0176(70mm)
flush mount adapter 229-7084 (25-28) 229-7094 (32-35) 229-7104(38-51) 232-2117(45-51) 229-7134(51-64) 232-2154(64-76)
bolt-on corner RH adapter 222-1088 (32/25) 229-7098 (40/32) 223-8108 (45mm) 232-8118(50mm)
bolt-on corner LH adapter 222-1089 (32/25) 229-7099 (40/32) 223-8109 (45mm) 232-8119(50mm)
bolt-on center adapter 229-7087(25mm) 223-8097 (32mm) 232-2110(50mm)
bolt-on center adapter 222-1087(32mm) 222-1097 (40mm) 223-8107 (45mm)
Caterpillar K series / Retainers K80 K90 K100 K100 K130 K150 K170
220-9090 220-9090 220-9090 220-9110 220-9130 233-7150 232-0170

Part Description

Mechanical Property

Teeth

Hardness HRC48-52, Impact strength(room temperature)≥18J

Adapter

Hardness HRC36-44, Impact strength(room temperature)≥20J

Grader Blades C80

Hardness HB280-320,Impact Strength≥7J(room temperature)

Cutting Edge 30MnB

Hardness HB440-480,Impact Strength≥25J(room temperature)

Cutting Edge 16Mn

Hardness HB330-370,Impact Strength≥40J(room temperature)



Advantage

1. Fast Delivery Time, lead time is around 35-40days.if stock availability, within one week.

2. Large Inventory, more than 5,000 items.

3. Strict Quality Management, testing hardness, impact strength, and test matchable one by one.

4. High impact strength and more wear material

5. Much more reasonable price

6. Professional, our factory has more than 20-year history on g.e.t field.

Quality Management

Impact testing

Impact Testing

spectrograph

Spectrograph

Hardness testing device

Tensile

tensile strength testing device

hardness

Stock Picture

stock-1
stock-3-4
stock-2

Shipment Picture

shipment-1
shipment-1
shipment-1
shipment-2

Production Process

1-Mould Design

1-Mould Design

2-Mould Processing

2-Mould Processing

3-Wax Model Making

3-Wax Model Making

4-Tree Assembly

4-Tree Assembly

5-Shell Building

5-Shell Building

6-Pouring

6-Pouring

7-Sprue Removal

7-Sprue Removal

8-Heat Treatment

8-Heat Treatment

9-Product Testing

9-Product Testing

10-Painting

10-Painting

11-Package

11-Package

About MINTER Profile

Ningbo Minter Machinery Co.,Ltd is a professional G.E.T located in China.Main products are Bucket teeth,adapter,cutting edge,bolt&nut,pin&retainer Chocky Bars and bucket wear protection. We provide direct replacement parts can be used for excavator,loader,bulldozers,scarifier,grader and snow plows,both construction sector and minning sector.
suit for most machinery brand like Caterpillar,Komatsu, Hitachi, Hyundai,Doosan,Volvo,JCB and some for Chinese machinery such as Sany XCMG,Liugong and so on.
There are complete & professional facilities in each production process.And we pay more attention to high standard for details from raw material selection to goods package and shipping. We are strict with delivery time.And our aime is simple,Committing to provide consistent high quality spare parts with excellent service for customers,to meet customers’ requirements and make effort to enlarge their market share and establish long-term cooperation with customers.
With strong technology term back-up and rich knowledge&experience on this field,we are able to provide R&D development to meet costomization requirement.
We focus on this industry. Join us to explore market together and pursuing what we want!

Q & A

1. What’s your delivery time?

Firstly, we will check our stock if availability, if no stocks, lead time is around 35-40days.

2.What’s your quality warranty ?

Promise no breakage happens.

Once breakage happens, we will have our technique team check and analyze. we will replace one by one for free if we should be responsible.

3.What kind of products you can offer ?

We are specialized in providing G.E.T parts like bucket teeth, adapter, cutting edge, side cutter, Protector, shank, ripper teeth, shank guard, fastners like bolt, nut,pin and retainers. Mainly for heavy machinery like excavators, loaders, dozers, motor graders and scrarifiers.

4.Are you a Manufacturer ?

Yes, we are a manufacturer located in Ningbo China. And we welcome to visit our factory.

5.Do you have Moq ?

No Moq. But if order quantity is less than 3tons, we have to surcharged for inland freight charge, port operation charge, file charge, export declaration charge etc..

6.What’s the biggest parts you can offer ?

We can provide PC1250, Caterpillar J800 spare parts,81 series as well. We are also striving into minning industry, expecting bigger parts can be casted later soon.
