Caterpillar loader bucket adapter direct replacement parts Bolt-on Center Adapter Two Strap 2 HOLES Adapters J350 series 3G3357

Short Description:

Caterpillar J series Corner bolt-on Adapter with two straps with one holes: 1U2208 1U2209 3G4258 3G4259 3G4308 3G4309 3G8308 3G8309 3G5358 3G5359

Caterpillar J series Corner bolt-on adapter with two straps with two holes: 6I9250 6I9251 8E5308 8E5309 8E5358 8E5359 6I8243 6I8244


Product Detail

Product Tags

Caterpillar Jseries adapter Description  Openning gap Item no. Bolt / Nut
J200 Bolt-on center adapter with two strap 2 holes 20mm 8E2184 4F3656 / 4K0367
J200 Bolt-on center adapter with two long strap 2 holes 20mm 9J4207 2J4771 / 2J3506
J250 Bolt-on center adapter with two strap 2 holes 25mm 1U0257 5P8136 / 8J2933
J300 Bolt-on center adapter with two strap 2 holes 25mm 1U0307 5P8136 / 8J2933
J300 Bolt-on center adapter with two strap 3 holes 25mm 3G5307 5P8136 / 8J2933
J300 Bolt-on center adapter with two long strap 2 holes 32mm 3G9307 5P8361/ 5P8362
J300 Bolt-on center adapter with two strap 2 holes 32mm 4T4307 5P8136 / 8J2933
J300 Bolt-on center adapter with two strap 2 holes 25mm 9J2307 1J3527 / 2J3507
J350 Bolt-on center adapter with two long strap 2 holes 45mm 1U1357 5P8361/ 5P8362
J350 Bolt-on center adapter with two strap 2 holes  40mm 3G3357 5P8361/ 5P8362

Caterpillar J series Corner bolt-on Adapter with two straps with one holes: 1U2208 1U2209 3G4258 3G4259 3G4308 3G4309 3G8308 3G8309 3G5358 3G5359

Caterpillar J series Corner bolt-on adapter with two straps with two holes: 6I9250 6I9251 8E5308 8E5309 8E5358 8E5359 6I8243 6I8244

Part Description

Mechanical Property

Teeth

Hardness HRC48-52, Impact strength(room temperature)≥18J

Adapter

Hardness HRC36-44, Impact strength(room temperature)≥20J

Grader Blades C80

Hardness HB280-320,Impact Strength≥7J(room temperature)

Cutting Edge 30MnB

Hardness HB440-480,Impact Strength≥25J(room temperature)

Cutting Edge 16Mn

Hardness HB330-370,Impact Strength≥40J(room temperature)



Advantage

1. Fast Delivery Time, lead time is around 35-40days.if stock availability, within one week.

2. Large Inventory, more than 5,000 items.

3. Strict Quality Management, testing hardness, impact strength, and test matchable one by one.

4. High impact strength and more wear material

5. Much more reasonable price

6. Professional, our factory has more than 20-year history on g.e.t field.

Quality Management

Impact testing

Impact Testing

spectrograph

Spectrograph

Hardness testing device

Tensile

tensile strength testing device

hardness

Stock Picture

stock-1
stock-3-4
stock-2

Shipment Picture

shipment-1
shipment-1
shipment-1
shipment-2

Production Process

1-Mould Design

1-Mould Design

2-Mould Processing

2-Mould Processing

3-Wax Model Making

3-Wax Model Making

4-Tree Assembly

4-Tree Assembly

5-Shell Building

5-Shell Building

6-Pouring

6-Pouring

7-Sprue Removal

7-Sprue Removal

8-Heat Treatment

8-Heat Treatment

9-Product Testing

9-Product Testing

10-Painting

10-Painting

11-Package

11-Package

About MINTER Profile

Ningbo Minter Machinery Co.,Ltd is a professional G.E.T located in China.Main products are Bucket teeth,adapter,cutting edge,bolt&nut,pin&retainer Chocky Bars and bucket wear protection. We provide direct replacement parts can be used for excavator,loader,bulldozers,scarifier,grader and snow plows,both construction sector and minning sector.
suit for most machinery brand like Caterpillar,Komatsu, Hitachi, Hyundai,Doosan,Volvo,JCB and some for Chinese machinery such as Sany XCMG,Liugong and so on.
There are complete & professional facilities in each production process.And we pay more attention to high standard for details from raw material selection to goods package and shipping. We are strict with delivery time.And our aime is simple,Committing to provide consistent high quality spare parts with excellent service for customers,to meet customers’ requirements and make effort to enlarge their market share and establish long-term cooperation with customers.
With strong technology term back-up and rich knowledge&experience on this field,we are able to provide R&D development to meet costomization requirement.
We focus on this industry. Join us to explore market together and pursuing what we want!

Q & A

1. What’s your delivery time?

Firstly, we will check our stock if availability, if no stocks, lead time is around 35-40days.

2.What’s your quality warranty ?

Promise no breakage happens.

Once breakage happens, we will have our technique team check and analyze. we will replace one by one for free if we should be responsible.

3.What kind of products you can offer ?

We are specialized in providing G.E.T parts like bucket teeth, adapter, cutting edge, side cutter, Protector, shank, ripper teeth, shank guard, fastners like bolt, nut,pin and retainers. Mainly for heavy machinery like excavators, loaders, dozers, motor graders and scrarifiers.

4.Are you a Manufacturer ?

Yes, we are a manufacturer located in Ningbo China. And we welcome to visit our factory.

5.Do you have Moq ?

No Moq. But if order quantity is less than 3tons, we have to surcharged for inland freight charge, port operation charge, file charge, export declaration charge etc..

6.What’s the biggest parts you can offer ?

We can provide PC1250, Caterpillar J800 spare parts,81 series as well. We are also striving into minning industry, expecting bigger parts can be casted later soon.
